S-9112-EATX
Build-to-Order - Compact Stylish 12x 5.25" Bay EATX Tower
  • 12x5.25" Bays Available for Mobile Drive Cage
  • Aluminum Front Panel with two USB 3.0 ports
  • Front Door Keylock design to secure data inside
  • Heavy Duty SGCC Construction
  • Compatible with Mini Redundant Power Supply
  • Support Standard I/O Slot
  • Support E-ATX Motherboard
  • Power and HDD LED Indicators
  • Two 120mm and One 80mm Cooling Fan
  • Internal 3.5" Bay for OS HDD



Product Introduction
The S-9112-EATX, external multi-bay tower, is designed specially for storage application and workstation. The wide variety of the tower with hard drive cages is able to easily max the hard drive capacity up to 20 bays for storing mass data. Quiet 120mm cooling fan enhances the ventilation inside. The S-9112-EATX, external multi-bay tower, with solid construction is a cost-effective and flexible solution for your critical data storage and professional workstation build.


Model NumberS-9112-EATX
RoHS Compliance VersionYes
Standard Drive Bays 3.5" Drive (internal): 1
5.25" Drives: 9
IndicatorsPower, HDD
SwitchesPower, Reset
Supported PSU TypeATX PS2/ mini-Redundant
Expansion Slots4
Material of Front BezelAluminum
Material of Main ChassisSGCC 1.0mm
Color of Front BezelBlack
Color of Main ChassisBlack
Front Connector1x USB 2.0
Motherboard Size9.6 x 9.6 (microATX, mini-ITX)
Cooling Fan1x80mm, 2x120mm
Dimensions (WxHxD)7.24" x 22.59" x 23.78"
183.9 mm x 573.8 mm x 604.0 mm
